DIMENSIONS
Length Overall:
|
30.0 ft.
|
/ 9.14 m
|
Beam:
|
9.0 ft.
|
/ 2.75 m
|
Draft:
|
1.67 ft.
|
/ 0.50 m
|
Draft (Air):
|
9.4 ft.
|
/ 2.87 m
|
Length on Trailer:
|
40.7 ft.
|
/ 12.4 m
|
Minimum Height on Trailer:
|
12.5 ft.
|
/ 3.81 m
|
CAPACITIES
Fuel (Main):
|
110 Gallons (2 x 55 Gal)
|
Fuel (Generator):
|
4.5 Gal
|
Personnel:
|
14
|
Seated Positions:
|
6
|
PERFORMANCE
Horsepower:
|
300
|
Max Speed:
|
30 knots
|
Cruising Speed:
|
22 knots
|
Max Range @ 22 knots:
|
140 NM
|
MACHINERY
Main Engines:
|
(2) Yamaha F150
|
Generator:
|
Honda EU6500is
|
|
|
HULL
Builder:
|
Scully, Morgan City, LA
|
Year Built:
|
2013
|
|
Construction:
|
Aluminum
|
SURVEY EQUIPMENT
Norbit iWBMSe Multibeam Echosounder
|
Applanix POS MV Inertial Navigation System
|
SonTek Castaway CTD
|
Trimble 540AP Antennas
|
Getac X500 Notebook
|
USM OTS-Compact w/ Hinge
|
ELECTRONICS
(2) Uniden UM380 VHF Radios
|
Standard Horizon VLH-3000 Loud Hailer
|
Furuno NAVnet 1834C Radar / WAAS GPS
|
Simrad AP70 Autopilot
|
MISCELLANEOUS EQUIPMENT
Davit w/ Electric Winch
|
Searchlight
|
Heat / AC Unit
|
|
