DIMENSIONS
Length Overall:
|
85 ft.
|
/ 25.91 m
|
Length Design Load Waterline:
|
81.3 ft.
|
/ 24.78 m
|
Beam Molded Amidships:
|
28.0 ft.
|
/ 8.53 m
|
Depth Molded to Main Deck:
|
11.5 ft.
|
/ 3.51 m
|
Tonnage (Gross):
|
137
|
GRT
|
Tonnage (Net):
|
93
|
NRT
|
CONSTRUCTION
All Steel
PROPULSION & STEERING
Main Engines:
|
(2) EMD 12-645-E2 @ 1,500 bhp
|
Propellers:
|
(2) Rolls Royce Stainless 4-Blade
78 in. x 62 in.
|
Gears:
|
(2) Falk 1235
2:9:1 Ratio
|
Rudders:
|
(2) Spade
|
Steering Stations:
|
(4) Pilothouse & Aft Station
|
PERFORMANCE
Speed (Free Route):
|
11.5 knots
|
Speed (Cruising):
|
10 knots
|
Bollard Pull:
|
26 short tons / 23.6 MT
|
Fuel Use/Range (Towing):
|
125 gph
|
Fuel Use/Range (Cruising):
|
60 gph
|
AUXILIARY MACHINERY
Generators:
|
(2) 55-kw Detroit Inline 6-71
|
Electrical Power:
|
60 Hz, 3 Phase
|
CAPACITIES
Fuel Oil:
|
28,268 USG
|
Lube Oil:
|
500 USG
|
Fresh Water:
|
3,609 USG
|
ACCOMMODATIONS
Total Personnel Capacity:
|
7
|
Staterooms:
|
4
|
Galley Seating:
|
5
|
Air Conditioning/Heating:
|
Central Air/Steam Heat
|
Cooler:
|
Reach-In
|
Freezer:
|
Reach-In
|
Sanitation:
|
MSD
|
|
|
ELECTRONICS
Radars:
|
(1) Furuno
(1) Simrad
|
Radios (SSB):
|
(1) Standard Horizon
|
Radios (VHF):
|
(4) Icom
|
Navigation Aids:
|
(1) Garmin Depth Sounder
|
Hailer/Talkback:
|
(1) Raymarine
|
GPS:
|
(1) Garmin
|
TOWING/ANCHOR HANDLING
Tow Winch Type:
|
Single-Drum
|
Tow Winch Model:
|
Marky 32 with Level Winder
|
Tow Winch Capacity:
|
2,500 ft. of 1⅝ inch wire
|
TUG’S MOORING
Anchor:
|
(1) 120 lb. Danforth
|
FIRE FIGHTING
On-Ship:
|
(2) 7 hp @ 50 gpm
|
Extinguishers:
|
Full Compliment
|
ROUTES
• Coastwise
• Great Lakes
• Registry
REGISTRATION
Flag:
|
USA
|
Home Port:
|
Albany, New York
|
Official Number:
|
287149
|
Hull Number:
|
791
|
Builder:
|
American Marine Corp.
|
Year Built:
|
1961
|
Call Sign:
|
WDD8915
|
CLASSIFICATION
United States Coast Guard
• Uninspected Towing Vessel Exam Certified
|
HEIGHTS
Wheelhouse Eye Level:
|
31 ft.
|
Top of Mast:
|
48 ft.
|
SPECIAL EQUIPMENT & AVIATION CERTIFICATION
Welding Machine:
|
(1) 250 amp
|
|
