OFFICIAL NUMBER
1211047
YEAR BUILT
2008
DIMENSIONS
Length:
|
165.0 ft.
|
/ 50.29 m |
Width:
|
43.5 ft.
|
/ 13.26 m
|
Depth:
|
12.0 ft.
|
/ 3.66 m
|
Coaming Height:
|
4.0 ft.
|
/ 1.22 m
|
Cargo Bin:
|
138.25 ft. x 36 ft. x 4 ft.
|
Area of Bin:
|
4,977 ft.2
|
Volume of Bin:
|
737 yd.3
|
Tonnage (Gross):
|
602 GT ITC
|
Tonnage (Net):
|
180 NT ITC
|
Skegs:
|
No
|
BUILDER
Erie Shipbuilding
DRAFT
Light Draft:
|
1.8 ft.
|
/ 0.56 m
|
Recommended Max Loaded Draft:
|
8.9 ft.
|
/ 2.72 m
|
CAPACITY
Max Capacity (at max recommended draft):
|
1,400
|
short tons
|
COMPARTMENTS
Rake Compartments:
|
2
|
Main Compartments:
|
6
|
LIGHTSHIP WEIGHT (Est.)
303 Long Tons
|
|
|
