DIMENSIONS
Length Overall:
|
81.7 ft.
|
/ 24.90 m
|
Length Design Load Waterline:
|
73.5 ft.
|
/ 22.40 m
|
Beam Molded Amidships:
|
27.2 ft.
|
/ 8.29 m
|
Breadth (Max):
|
28.7 ft.
|
/ 8.75 m
|
Depth Molded to Main Deck:
|
11.1 ft.
|
/ 3.38 m
|
Draft (Light):
|
9.5 ft.
|
/ 2.90 m
|
Draft (Maximum):
|
11.5 ft.
|
/ 3.50 m
|
Tonnage (Gross):
|
148
|
GRT
|
Tonnage (Net):
|
101
|
NRT
|
Maximum Height (Above Water):
|
28.0 ft.
|
/ 8.53 m
|
CONSTRUCTION
All Steel
PROPULSION & STEERING
Main Engines:
|
(2) Caterpillar D-399
2,250 bhp @ 1,225 rpm
|
Propellers:
|
Stainless 4-Blade
88 in. x 58 in.
|
Gears:
|
(2) Caterpillar #7261
4:22:1 Ratio
|
CAPACITIES
Fuel Oil:
|
25,000 USG
|
Lube Oil:
|
650 USG
|
Hydraulic Oil:
|
100 USG
|
Potable Water:
|
4,600 USG
|
ACCOMMODATIONS
Full Crew:
|
5
|
Short Crew:
|
4
|
|
|
ELECTRONICS
Radars:
|
(2) Bridgemaster 251/8
|
Radios (SSB):
|
(1) SEA 222
|
Radios (VHF):
|
(2) Standard Titans
(2) Standard H8220
|
Auto Pilot:
|
(1) Sperry 8T
|
GPS:
|
(1) Echotec
(1) Trimble
|
TOWING/ANCHOR HANDLING
Tow Winch Type:
|
Double Drum
Hydraulic
|
Tow Winch Wire on Tow Drum:
|
1,800 ft. of 1¾ inch
|
Tow Winch Wire on Anchor Drum:
|
1,200 ft. of 1¾ inch
|
TUG’S MOORING
Anchor:
|
(1) 1,000 lb. Danforth
|
ROUTES
• Coastwise
• Registry
REGISTRATION
Flag:
|
USA
|
Home Port:
|
Port Newark, New Jersey
|
Official Number:
|
567631
|
ACT Number:
|
0207
|
Builder:
|
Marine Power & Equipment
|
Year Built:
|
1975
|
Year Rebuilt:
|
1988
|
Call Sign:
|
WDE5943
|
|
